Choisissez votre modèle :

RTP80/TS7 - Rugosimètre à écran tactile, unité de palpage à palpeur interchangeable à patin
TL2 - Support à colonne pour positionnement de rugosimètre SM
Logiciel " Studio Full " pour analyse sur PC

The modular rugosimeters of the RTP-80 Series combine the advantages of a portable and lightweight system with the characteristics of a laboratory rugosimeter, this versatile instrument guarantees accurate and reliable measurements. Thanks to The Large 5.7′ colour LCD display for touch use, the operator can intuitively set the roughness meter. The data as well as the graphs are displayed on the screen, so it is very easy to analyze the results.
It is also possible to edit roughness values and graphics with the built-in printer.
This powerful system makes it possible to directly measure roughness values at the production site or at the quality service level.

The TS7 Probe Unit is very handy and can be used in all directions. The probe can be positioned in many ways to easily measure roughness on parts of complex shapes or of mass and volume.”


Control and measurement unit RTP80:

  • Roughness, profile and ripple parameters according to international standard standards
  • Unit of measurement μm or μinch
  • Measuring speed: 1 mm/sec or 0.5 mm/sec
  • Resolution: 0.001 μm (0.04 μinch)
  • Cut-Off: 0.08-0.25-0.8-2.5-8 mm
  • Number of Cut-Off: from 1 to 19, configurable.
  • Measuring range, up to 1000 μm
  • Memory, 1000 measurements
  • GAUSS, ISO 11562 and ISO 3274 filters
  • Large 5.7’ colour LCD display, touch screen, 320 240 resolution, 256 colours
  • Integrated thermal printer
  • 3-key keyboard for direct access to main functions
  • Very intuitive graphical touch interface
  • Tolerances on all parameters
  • RS232C output for connection to a PC via software

Measurement Studio:

  • Power supply, battery 12V/ AC220V
  • Operating temperature, 10 to 40°C

TS7 Probing Unit:

  • Measuring principle, differential induction
  • Probe with skid
  • Measuring range, 120μm
  • Measuring stroke up to 25 mm
  • Return speed: 2 mm/sec
  • Measurement position, horizontal, vertical, 90°, 180°
  • Contact force according to ISO3274
  • Probe height adjustment up to 50 mm
  • Dimensions/Weight, 145x85x45 mm/ 500 g
  • Supplied with removable probe SB10 ref.1.325 (there are 10 probes for TS7, see following pages «probes for rougosimeters»), diamond radius 5μm, 90° (on request 2μm, 60°)
